 Standard 1U case, advanced CPU and GPU decoding technology is adopted |
| Web-based remote network management software |
| Support for multiple input protocol: UDP, RTP, RTSP, RTMP, HTTP, SRT, etc. |
| Support 10GBE or 25GBE SFP fiber interface output |
| Support SMPTE ST2110 standard protocol output, including SMPTE ST2110-10/20/30/40 |
| Support video input formats such as H.265/HEVC, H.264/AVC, AVS, AVS+, AVS2(optional), etc. |
| Support input of MPEG-1 layer 2, MPEG-1 layer 3, LC-AAC, HE-AAC, AC3, EAC3 and other audio formats |
| Support two gigabit ethernet ports, and can flexibly configure the physical input channel of IP programs |
| Support image overlay and other software function customization |
| Doteck D6 series 4K ST 2110 IP decoder can decode mainstream video compression standard streams such as H.265/HEVC, H. 264/AVC, AVS, AVS+, AVS2(optional). Under the harsh conditions of low network bandwidth, it also has excellent video and audio fault tolerant capacity. It can adapt to various complex network audio and video application environments and supports multiple protocol input: UDP, RTP, RTSP, RTMP, HTTP, SRT, etc.. |
Input interface |
RJ45(1000M) |
Network protocol |
UDP, RTP, RTSP, RTMP, HTTP, SRT |
Channel |
1-channel 4K, or 4-channel HD stream |
Video format |
H.265/HEVC, H.264/AVC, AVS, AVS+, AVS2(optional) |
Audio format |
MPEG-1 layer 2, MPEG-1 layer 3, LC-AAC, HE-AAC, AC3, EAC3 |
Transport stream format |
SPTS, MPTS, FLV, HLS |
Standard |
ST2110 |
Channel |
1-channel 4K, or 4-channel HD uncompressed IP stream |
Output resolution |
2160p60/50/30/25
1080p60/50/30/25
1080i60/50
720p60/50/30
576p25, 480p30
576i50, 480i60 |
Interface |
10GBE or 25GBE SFP fiber optic interface |
Management |
Web-based remote network management software |
Dimension(H×W×D, mm) |
44×433×498(mm) |
Operation temperature |
0-50℃ |
Relative humidity |
0-95%, non-condensing |
Power Supply |
130-260VAC, 50/60Hz |
|
